Mobile filter unit MAL® PJF 370

Product Number

CTMALPJF370

The MAL® PJF 370 mobile filter unit is used wherever dust is generated by blasting, grinding, cutting etc. and as a supplement to mobile abrasive suction and recycling systems. The dust generated by the processes is drawn into the filter unit by means of a radial fan. Detail description

Detailed description

The MAL® PJF 370 mobile filter unit is used wherever dust is generated by blasting, grinding, cutting, etc., and as a supplement to mobile abrasive suction and recycling systems. The dust generated by the processes is drawn into the filter unit by means of a radial fan. The dust-containing air is evenly distributed over the filter inserts in the filter body and flows outwards from the inserts. Clean air flows through the filter cartridges, while the dust contained in the air mass cannot penetrate and sticks to the outside of the cartridges. After passing through additional H13 filter cartridges, the cleaned air is discharged into the open space. The dust falls through the collection hoppers into the dust container. The filter unit is suitable for cleaning dry air contaminated with dust.

For more information about MAL MECHATRONIK products, please visit www.mal-mechatronik.com.

Technical data

Manufacturer: MAL Mechatronik

The engine: 2 x 11 kW

Power supply: 400 V

Total differential pressure: 2 500 Pa

Air displacement at Δp. 2500 Pa: 22 000 m³/h

Separation efficiency: < 0,1 mg/m³

Filter class: H13

Weight: ± 3 000 kg

Dimensions (L x W x H) 5 420 x 1 570 x 2 700 mm

Installation height (in ready state): from 3 140 - up to 3 590 mm
