FALCH® Trail Jet 30 1000-14-0-d

Product Number
CTG360
Mobile high-pressure equipment FALCH® Base Jet 30 1000-14-0-d (with operating pressure 100 – 1000 bar, diesel-powered) designed for ultra-high pressure water jet blasting technology from the proven German manufacturer FALCH. Detail description

Mobile high-pressure equipment FALCH® Base Jet 30 1000-14-0-d (with operating pressure 100 - 1000 bar, diesel-powered) designed for ultra-high pressure water jet blasting technology from the proven German manufacturer FALCH.

The water jet (static or rotary) allows operating pressures up to 3,000 bar. With this technology, it is possible to remove damaged coatings even of greater thickness from large areas or to clean them perfectly from contaminants. The ultra-high and high pressure cleaning method is suitable for metal and concrete substrates in areas where conventional abrasive blasting is not possible, or as a pre-treatment for removing deposits and contaminants or existing coatings prior to abrasive blasting and subsequent coating. More at www.falch.com.

Manufacturer: Falch
Operating pressure: 100 - 1000 bar
Flow: 8 - 13 l/min
Noise level (LpA, LwA + 1.5 dB): 76 db, 97 db
Fuel consumption at 60% load: 4.3 l/h (diesel)
Power, pumping speed, inlet water pressure, max. inlet water temperature: 28 kw, 1 057 rpm, 2.8 bar, 40°C
Weight, vertical load: 900 kg, 100 kg
Operating time (hours/day): 24/1
Diesel engine, max. power/performance, speed, idle speed, cooling system: 36,4 kw, 31 kw, 1 850 rpm, 1 000 rpm, 4 cyl., 3 620 cc, water
Warranty period: 24 months
Antifreeze system: Contained by
Water tank capacity: 200 l
Water shortage safety switch: Contained by
Standard nozzle size: 019 USgal/min
Fuel oil consumption at 60% load: 4.5 l/h
Length x width x height: 3 250 x 1 600 x 1 850 mm
